Product Introduction
Modular space Capsule House is an aerospace-inspired modular accommodation system designed for deployment in harsh environments and remote locations.
Core Product Specifications
|
Category |
Parameter Item |
Specific Details |
|
Basic Product Info |
Product Model |
Space Capsule house |
|
Product Type |
Independent Modular Capsule, Multi-Unit Cluster (2–6 units) |
|
|
Architectural Style |
Aerospace Cylindrical Design (wind-resistant structure) |
|
|
Core Features |
Ultra-low temperature resistance (-50℃), High-temperature tolerance (60℃), 120km/h wind resistance, Grade 8 earthquake resistance, Waterproof (IP67), Dustproof (IP66), Self-sustaining energy/water, Smart environmental control |
|
|
Core Performance |
Service Life |
20 Years (under extreme environment use) |
|
Warranty Period |
12 Months |
|
|
Customization Service |
Supported (environment-specific upgrades, capacity expansion) |
|
|
Material & Specifications |
Main Material |
Galvanized square tube frame, polyurethane insulation layer |
|
Product Dimensions (D×H×L) |
Different models have different sizes |
|
|
Shipping Package |
1 piece |
Standard & Optional Configurations
Standard Configuration (Ready-to-Use)
Structural System
· Q235B/Q355B welded steel frame structure
· Anti-corrosion hot-dip galvanized coating system
· Modular prefabricated structural assembly
Envelope System
· Insulated steel wall panel system
· Double-glazed insulated window system
· EPDM gasket-based sealing interface system
Mechanical System
· Split air conditioning system interface
· Electric underfloor heating system
· Internal HVAC duct pre-routing channels
Electrical System
· Pre-wired internal electrical harness system
· AC 110V / 220V distribution panel compatibility
· Industrial-grade waterproof socket outlets
Interior Base Module
· Bathroom wet/dry separation module
· Bed platform structural base
· Integrated interior partition framework
Optional Configurations (Project-Based Upgrades)
Extreme Climate Package
· Reinforced laminated safety glass system
· High-load underfloor heating system
· Thermal bridge reduction envelope upgrade
Energy Independence System
· 1000W photovoltaic input system
· 400Ah lithium battery storage system
· 500W wind turbine auxiliary input
· Hybrid off-grid power management interface
Water System Module
· 200L integrated water storage tank
· Greywater separation discharge system
· Rainwater / snow collection pre-interface
· Reverse osmosis purification module interface
Operational Expansion Modules
· 6-person expanded occupancy structural layout
· Shared kitchen infrastructure module
· External equipment storage container (2m³, waterproof rated)
Core Features
Welded Q235B/Q355B steel frame with continuous load-bearing structure
Hot-dip galvanized corrosion protection system (marine exposure adaptable)
Thermally broken window frame system reducing conductive heat loss
EPDM gasket compression sealing system for envelope air-tightness
Pre-routed electrical conduit embedded within structural frame cavities
Roof-mounted lifting points designed for crane rigging load transfer
Greywater separation piping with dedicated non-potable discharge line
Manufacturing & Quality Control System
Production capability:
Annual production capacity: 20,000+ modular units
Factory-controlled prefabrication workflow system
Standardized modular assembly line production
Quality Verification Stages:
Raw material incoming inspection (steel, insulation, glass certification check)
Structural welding inspection (visual + non-destructive testing sampling)
Waterproof simulation testing (spray test simulation ≥150 mm/h rainfall equivalent)
Load-bearing verification testing on structural frame samples
Electrical insulation resistance testing (pre-shipment FAT testing)
Final assembly inspection and system functional verification
Compliance & Certification
Structural design alignment
Eurocode / AISC / equivalent regional standards (project dependent)
Fire safety compliance
EN / UL / local building authority requirements (configurable)
Electrical system compliance
CE / UL electrical component integration option
Welding standard
AWS D1.1 or equivalent industrial welding certification process
Export documentation support
Technical file, material traceability, compliance mapping
Case Studies - Alpine Resort Deployment (Russia)
Project context:
· Location: Russian ski resort region
· Units deployed: 8 capsule houses
Operational challenges before deployment:
· Extreme winter temperatures (-30°C and below)
· High diesel dependency for heating systems
· Frequent snow blockage requiring manual clearing
· Slow expansion due to long construction cycles
Results after deployment:
· Stable internal temperature maintained at 22°C
· Energy cost reduction: approx. 55%
· Occupancy rate increase: 80% → 98%
· Significant reduction in maintenance downtime
· Higher guest retention due to improved comfort conditions
FAQ
